Allen & Heath DX168 16x8 96kHz Portable DX Expander

Allen & Heath
Sale price
$1,799
List price
$1,999
You save
$200 (11%)
Available now — ships from our shop or direct from the manufacturer

The Allen & Heath DX168 is a 96kHz portable stage box with the same dLive-class preamps found in A&H's flagship systems. 16 inputs and 8 outputs on stage, one Cat5e cable back to the mixer, and a second port for redundancy or daisy-chaining.

Highlights

  • 16 XLR mic/line inputs with +48V phantom and recallable preamps (+5 to +60dB gain, -20dB pad)
  • 8 balanced, relay-protected XLR line outputs
  • DX protocol, 96kHz
  • Single Cat5e run up to 100m (328 ft)
  • Works with SQ / SQ+, Avantis, dLive, AHM-64 and the 96kHz Qu models (not compatible with Qu Classic)
  • Two locking EtherCON ports: redundant link or daisy-chain a second DX expander
  • Floor box with bumpers and handle; optional 4U rack kit

Specs

  • Power: 100–240V 50/60Hz
  • Dimensions: 16.1" x 7.5" x 7.3" (410 x 190 x 185mm)
  • Weight: 10.6 lb (4.8kg)

Condition: New, with full Allen & Heath manufacturer warranty.
